In October, INFiLED built an LED curved screen for the Pingshanwei subway station on Shenzhen Metro Line 16. This screen made of QM series has unrivaled clarity and bright colors, which can well display commercial advertisements and other promotional content to passengers entering and exiting the station.

Pingshanwei Station, a newly opened subway station in the fall of 2022, is also the first transfer station in Pingshan District, Shenzhen, Line 16 and Line 14 meet here. In view of the high ridership the place is suitable for commercial promotion, the subway operator decided to install a screen around a corner near this station entrance-exit to attract advertisement putting. With proven technologies in the production and construction of curved screens, INFiLED won the tender for this installation project.

Compared with conventional flat screens, the creation of curved screens requires higher precision in the splicing of the LED panels. In this project, the INFiLED technical team measured the curvature of the screen installation location in advance, determined the curved screen structure to be made, and customized a batch of LED panels accordingly, eventually creating a screen with natural and smooth curvature.

In terms of color expression, the curved screen installed in the subway station has a pixel pitch of 1.56mm and a resolution of 12288*2808, with a distinct visual presentation and high color reproduction; in addition, the LEDs of this screen adopt IMD encapsulation technology, which is characterized by superior color purity and wide color gamut, which can well express the details of the picture.

In other respects, this curved screen also has many advantages. First, it is equipped with a high-efficiency power supply system, which can effectively avoid local overheating of the screen surface, and maintain the light quality and uniformity of the LEDs in a good state; Second, it supports front maintenance. In the event of a screen failure, repairmen can easily remove the damaged module for service using a vacuum suction tool (optional).

About INFiLED QM series

QM series is one of INFiLED’s most remarkable LED displays, it adopts advanced IMD&SMD encapsulation technology. Features a wide color gamut, high brightness, and high contrast ratio of 20000:1; this series can offer an exquisite and vivid picture with vibrant color and rich detail. It is the best solution for a range of indoor applications including control & command centers, studios, stations, and classrooms.

About INFiLED

INFiLED is an international high-tech enterprise specializing in the R&D and manufacturing of large-scale LED video equipment. INFiLED's products have been exported to 87 countries and applied in various fields including transportation, events, conferences, and virtual filming. Focusing on independent innovation and continuous improvement, INFiLED is striving to be a top-brand LED screen manufacturer.
